1

Operating Wavelength

nm

1250～1610

2

Insertion loss

dB

2.0

1.2

3

reflection loss

dB

55db（Min）

60

4

Polarization-dependent loss

dB

0.1

0.06

5

switching loss

dB

1.2

0.8

6

optical splitting Loss

dB

0.5

7

Repeat ability

dB

±0.02

±0.01

8

Isolation

dB

-50

-60

9

Input optical power

dBm

24

+10

-16（Min）

10

Switching time

ms

20

10

11

Service life of switch

times

1,000,000（Min）

12

Range of power switching

dBm

+24dBm～-15dBm

13

Radio frequency test range

dBm

+24dBm～-5dBm

If less then-5dBm,Please refer to the radio frequency test

14

Control mode

Automatic or  manual

15

Input/output optical interface

FC/APC or SC/APC

16

Operation temperature

°C

-5～+55

17

Storage temperature

°C

-30～+70

18

Humidity

95%

Uncondensed

19

Dimension

mm³

440×270×44

20

Power

W

＜6
